For coating thickness measurement on magnetic metals
Handheld instrument with built-in probe for measuring coating thickness with the magnetic induction method. For measuring non-ferrous metallic and non-conductive coatings on steel or iron (NF/Fe and Iso/Fe).
Areas of application:
– Coatings of paint, lacquer or plastic on steel or iron (Iso/Fe)
– Coatings of copper, brass, zinc, tin and chrome on steel or iron (NF/Fe)
Equipment and features:
– Intuitive, menu-led operation; graphical display
– Auto-rotating display (like a smartphone)
– Wear-resistant hard metal probe tip
– Measurement modes: Standard, IMO PSPC (90/10 rule) and SSPC-PA2
– Internal data storage: 10,000 readings
– USB interface for bi-directional data transfer.
– Support CD with FISCHER DataCenter software for evaluating and archiving measured values, as well as PC-DATEX software for exporting data to Excel
– Manufacturer’s certificate
Measurement range:
0 – 2500 µm NF/Fe
Price includes carrying case, dust cover, connection cable MP0R-USB, shoulder strap, 2x LR6.AA batteries, Fe base, KAL-N 75 µm, operation manual.
MEASUREMENT METHOD
Magnetic Induction
APPLICATION
Paint; varnish or plastic coatings on steel or iron (ISOFE), Zinc; chromium; copper coatings on steel or iron (NFFE)
COATING
Electrically Non-Conductive, Non-Ferrous Metals
BASE
Ferromagnetic Metals
GENERAL FEATURES
Display of mean value;, MIN; MAX and number of all measurements stored in the instrument memory Max. memory for 10000 individual readings, Standard deviation
MEASURING MODES
ASTM D7091, DIN EN ISO 2178, IMO PCPC, SSPC-PA2
PROBE
Integrated Probe
MEASUREMENT RANGE
0,0 μm – 2500,0 μm
